Inlet diameter | φ 2.0-φ 2.6 mm | ||||||
Outlet diameter | Φ 0.15-Φ 0.70 mm | ||||||
Number of produced wires | 8 x copper bare i.e. copper tinned(1 Levels, with 8 wires) | ||||||
Drawing speed | Max. 28 m/s | ||||||
Drawing passes | Max. 22 | ||||||
Drawing rings | 100mm with 8 grooves, For separate and parallel wire guidance Material: tungsten carbide or zirconium oxide | ||||||
Wire elongation | 11 x 25% / 5 x 19.44 % /3 x 9.04% Adjustable and quick die change | ||||||
Drawing dies | φ max. 28mm alternatively φ = max. 25.4 mm max. 12 mm thickness | ||||||
Compressed air supply | 6 bar overpressure (7 x 105 Pa), water- and oil free | ||||||
Bobbin | DIN 630 ( Drawing will be provided by users) | ||||||
Operation direction | from left to right | ||||||
Noise level | < 85 dbA (Except for main motor) | ||||||
Production efficiency | 8 x φ 0.150mm at v = 28.0m/s 8 x φ 0.203 mm at v = 25.0m/s 8 x φ 0.250 mm at v = 23.0m/s 8 x φ 0.300 mm at v = 15.0m/s 8 x φ 0.400mm at v = 12.0m/s Production efficiency for tinned wires at production speeds reduced by about 20% | ||||||
item | value |
Place of Origin | China |
Condition | New |
Video outgoing-inspection | Provided |
Machinery Test Report | Provided |
Marketing Type | Hot Product 2021 |
Warranty of core components | 1 Year |
Core Components | PLC, Engine, Bearing, Gearbox, Motor, Pressure vessel, Gear, Pump |
Voltage | Customized |
Power | Customized |
Dimension(L*W*H) | Customized |
Warranty | 1 Year |
After Warranty Service | Video technical support, Online support, Spare parts, Field maintenance and repair service |
Local Service Location | None |
Showroom Location | None |
Applicable Industries | Building Material Shops, Manufacturing Plant, Energy & Mining |
Material | copper |
